Technaxx TX-23 User Manual

4.2. Set WIFI connection
(b) Set SSID (Wireless router name) / Password
(1) Enable “Start WiFi setting”.
(2) Click “Scan” to choose the WIFI connection “Network name [SSID]” (it is your
Wireless router name).
(3) Wireless Security Type & Data Encryption will be selected automatically after the
right Network Name (SSID) is selected. Please here no manual changes!
(4) Input the WIFI connection “Password” and click “OK” to save.
(a) Right mouse
click then you
see the device ID
shown under
LAN.
Then select “Set
WIFI ” on the
menu popped
out.
NOTE:
After saving WIFI settings
the camera will restart
automatically and then you
can take off the LAN cable
after the camera boots up
successfully in 1–2 minutes
and you saw the camera ID
in BLUE under LAN.

Technaxx TX-23 Specifications

General

Type	IP security camera
PTZ control	No
Alarm input/output	Yes
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Form factor	Dome
Mounting type	Ceiling/wall
Product color	Black
Maximum resolution	- pixels
Supported video modes	-
Video formats supported	M-JPEG
Angle of rotation	355 °
Minimum illumination	0.5 lx
Sensor type	CMOS
Optical sensor size	1/4 \
Optical zoom	- x
LED type	IR
Night vision distance	10 m
Number of illumination LEDs	10
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Supported network protocols	TCP / IP
Ethernet LAN (RJ-45) ports	1
Audio formats supported	ADPCM
DC output current	2 A
Power consumption (typical)	4 W
Operating temperature (T-T)	-5 - 55 °C
Minimum RAM	1024 MB
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	110 mm
Width	100 mm
Height	130 mm
Weight	282 g
