Technaxx TX-23 User Manual

6.1.1. Set the IP address
6.1.2. Set WIFI connection
(refer to 4.2. WIFI connection)
6.1.3. Set the local video plan
Press with the right mouse at the camera and select “Set the local video plan”.
Set local video record plan, the software will auto record the camera schedule on the
computer after the My Secure is running, as shown below:
Enable “7*24” to record all the time from Sunday to Monday
Click “Add” to select the day it and set the start and End time for video recording
Click “Apply” to save the current video equipment plan settings.
The default setting is camera use DHCP. Camera
auto gets IP address from network router.
It is a easy way for normal customer who do not
know how to set IP address manually.
Activate the „Set WiFi Setting“ and press the
button search. Select your “Router” Network
Name and put the right password from your
WiFi router. Here no more changes!

Technaxx TX-23 Specifications

General

Type	IP security camera
PTZ control	No
Alarm input/output	Yes
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Form factor	Dome
Mounting type	Ceiling/wall
Product color	Black
Maximum resolution	- pixels
Supported video modes	-
Video formats supported	M-JPEG
Angle of rotation	355 °
Minimum illumination	0.5 lx
Sensor type	CMOS
Optical sensor size	1/4 \
Optical zoom	- x
LED type	IR
Night vision distance	10 m
Number of illumination LEDs	10
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Supported network protocols	TCP / IP
Ethernet LAN (RJ-45) ports	1
Audio formats supported	ADPCM
DC output current	2 A
Power consumption (typical)	4 W
Operating temperature (T-T)	-5 - 55 °C
Minimum RAM	1024 MB
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	110 mm
Width	100 mm
Height	130 mm
Weight	282 g
