Technicolor CGM4231 User Manual

1/8/2018 Proprietary and Confidential - Technicolor 120
Bitmap
Top tab
Bottom tab
Section
Field(s)/Pop-
ups
wireless5Enable(61)**
wireless5ABGNMode(62) **
Wireless
Radio Settings
Network Mode
wireless5SSID(63) **
Setup
Quick Setup
Wireless
Network Name
Network
(SSID)
Wireless
Radio Settings
Network Name
(SSID)
wireless5BroadcastSSID(64)
Wireless
Radio Settings
SSID Broadcast
**
wireless5Channel(65) **
Wireless
Radio Settings
Channel
wireless5ChannelWidth(66)
Wireless
Radio Settings
Channel Width
**
wireless5Security(67) **
Wireless
Wireless Security
All fields
wireless5Wps(68) **
Wireless
WPS
all fields
wireless5Advanced(69) **
Wireless
Advanced Settings
All fields
wireless5AccessControl(70)
Wireless
MAC Control
All fields
** +
wireless5Bridging(71) ** +
Wireless
wreless5Wmm(72) **
Wireless
QoS
Quality of
WMM Support
Service
wireless5AckEnable(73) **
Wireless
QoS
Quality of
No ACK
Service
ping(74)
Administration
Diagnostics
igmpProxy(75)
Administration
Management
IGMP Proxy
IGMP
* - These bits are no longer available in GA but they are still available in some customer
specific releases. ** - These bits will be available only on a model with 2.4GHz and 5GHz
support.
+ - These bits are not supported currently.
These should be encoded as a hex string. Presently these will be represented by 20 hex digits
each of which encapsulates 4 bits. The MSB of this hex string would be bit zero and LSB
would be bit 79 though (we currently have defined onlyup to bit 76).
Examples:
