1/8/2018 Proprietary and Confidential - Technicolor 81
IKE peer. Both character and hexadecimal values are
acceptable in this field, e.g.,
My_@123 or 0x4d795f40313233. Note that both sides must
use the same Pre--Shared Key.
Key Lifetime:
This field specifies the lifetime of the IKE generated key. If
the time expires, a new key will be renegotiated
automatically. The Key
Lifetime may range from 300 to 100,000,000 seconds. The
default lifetime is 3600 seconds.
Enable:
To Enable the Key Management.
Tunnel Name:
This field specifies Tunnel Name.
Setting the values of different parameters:
• Click on the parameter and change the values in valid range
• Select the corresponding button
• Click on the corresponding drop down menu and select the required values
• Press Save
Below figures shows the value settings for different parameters.
Figure 8.9
