08
Parts Name
Numbers such as (
00) indicate reference pages.
Balance weight (
11)
Stylus pressure
control (
14)
Arm lock
(
16)
Arm-height
adjuster
(
16)
Anti-skating
control
(
15)
Arm clamp (
14)
Arm rest (
14)
Cue lever (
14,19)
Speed select buttons (
18)
Turntable (
10)
Turntable mat (
10)
Cartridge
(
6,18,21)
Stylus
(
6,18,21)
Centre spindle (
10)
Insulator (
13)
START-STOP button (
18)
ON/OFF (power) [
]
(
18)
Head shell (
11,21)
Locking nut (
11,21)
Tone arm (
14,16)
Front
SL-100CEB210118.indd08SL-100CEB210118.indd08 2021/03/2317:27:582021/03/2317:27:58

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Technics SL-100C and is the answer not in the manual?

Technics SL-100C Specifications

General IconGeneral
Drive MethodDirect Drive
Turntable Speeds33 1/3 RPM, 45 RPM
PlatterAluminum Die-cast
Tonearm TypeStatic Balance
Phono OutputYes
Weight9.9 kg
MotorBrushless DC Motor
Wow and Flutter0.025% W.R.M.S.
Effective Tonearm Length230 mm
Overhang15 mm
Headshell Weight7.6 g
Power SupplyAC120 V, 60 Hz
Power Consumption8 W
Starting Torque1.5 kgf·cm
Tracking Error AngleWithin 2° 32'
Tonearm Height Adjustment Range0-6 mm
Frequency Response20 Hz to 20 kHz
Cartridge Weight Range5.6 - 12.0g (without auxiliary weight), 14.3 - 20.7g (including headshell)
Signal-to-Noise Ratio78dB (DIN-B)
