Technics SX-PX554

Ref. No. Part No. Part Name & Description
Pcs
Remarks
IC4 HD74LS138P 3 TO 8 DECODER 1 MKB2
IC4 M5218AL OPERATIONAL AMP 1 FJASP
IC4 T7WU04FTE12L TRIPLE INVERTER 1 MAIN
IC5 M5218AL OPERATIONAL AMP 1 FJASP
IC5 T7WU04FTE12L TRIPLE INVERTER 1 MAIN
IC6 M5218AL OPERATIONAL AMP 1 FJASP
IC6 QS1GX3C04005 4M BIT MASK ROM 1 MAIN
IC7,C8 M5218AL OPERATIONAL AMP 2 FJASP
IC8 M5256DFP70LL 256K BIT STATIC RAM 1 MAIN
IC9 M5218AL OPERATIONAL AMP 1 FJASP
IC9 M5256DFP70LL 256K BIT STATIC RAM 1 MAIN
IC10 D97315GD201 TONE GENERATOR LSI 1 MAIN
IC10 M5218AL OPERATIONAL AMP 1 FJASP
IC11 LH5P832N-10 256K BIT PSEUDO STATIC RA 1 MAIN
IC11 M5218AL OPERATIONAL AMP 1 FJASP
IC12 QCPL-260L PHOTO COUPLER 1 FJASP
IC12 QSIGX3C64002 64M BIT MASK ROM 1 MAIN
IC14 TC7W08FTE12L DUAL 2-INPUT AND GATES 1 MAIN
IC15 TC7W04FTE12L TRIPLE INVERTER 1 MAIN
IC16 D97315GD201 TONE GENERATOR LSI 1 MAIN
IC17 LH5P832N-10 256K BIT PSEUDO STATIC RA 1 MAIN
IC18 QSIGX3C64003 64M BIT MASK ROM 1 MAIN
IC20 TC7W08FTE12L DUAL 2-INPUT AND GATES 1 MAIN
IC21,22 PCM1734EA-E2 D/A CONVERTER 2 MAIN
IC26 M5218AFPE3 OPERATIONAL AMP 1 MAIN
JK1 QJSG007AA PEDAL IN 1 FJASP
JK1 QJSG017AA COMPUTER 1 COM
JK1 SJJG100A HEADPHONE 1 1 HP
JK2 QJSG016AA MIDI IN 1 FJASP
JK2 SJJG100A HEADPHONE 2 1 HP
JK3 QJSG016AA MIDI 1 FJASP
JK5-K8 QJJG003AA LINE OUT,AUX IN 4 FJASP
JK9 SJVD0203B AC INLET 1
FJASP
JR1-R3 ERDS2T0 0,1/4W 3 PKB
L1 QLQGT1B100MA 10UH 1 MAIN
L1 QLQGT2T100LA 10UH×2 1
FJASP
L1 QLQGT3T131LA 130UH×3 1 HP
L2 QLBG005A COIL 1
MAIN
L2,L3 QLQGT3T131LA 130UH×3 2 FJASP
L4 QLQGT1B101KA 100UH 1 MAIN
L4 QLQGT3T131LA 130UH×3 1 FJASP
L5 QLQGT1B100MA 10UH 1 MAIN
L5 QLQGT3T131LA 130UH×3 1 FJASP
L6 QLBG005A COIL 1
MAIN
L6 QLQGT3T131LA 130UH×3 1 FJASP
L7 QLBG005A COIL 1
MAIN
L7 QLQGT3T131LA 130UH×3 1 FJASP
L8,L9 ERJ6GEY0R00V CHIP JUMPER 2 MAIN
L11,12 ERJ6GEY0R00V CHIP JUMPER 2 MAIN
L14-27 ERJ6GEY0R00V CHIP JUMPER 14 MAIN
L29-31 ERJ6GEY0R00V CHIP JUMPER 3 MAIN
L33-35 ERJ6GEY0R00V CHIP JUMPER 3 MAIN
30
