Technics SX-PX554

Ref. No. Part No. Part Name & Description
Pcs
Remarks
L41-45 ERJ6GEY0R00V CHIP JUMPER 5 MAIN
L46-49 ERJ6GEYJ471V 470 4 MAIN
L50 ERJ6GEY0R00V CHIP JUMPER 1 MAIN
LED1 T512SRDBS119 7 SEGENTS DISPLAY 1 CPR
P1 QPGG0481AB PACKING CASE(SX-PX554M) 1
PCB1 SXPG235021 MAIN P.C.B. 1
PCB2 SXPG2241191A FJASP E P.C.B. 1 EB EZ EG EX GN
PCB2 SXPG2241201A FJASP M P.C.B. 1 P,PC,PY
PCB2 SXPG2241211A FJASP X P.C.B. 1 X,XA
PCB3 SXPG227871A CPL P.C.B. 1
PCB4 SXPG227871B CPR P.C.B. 1
PCB5 SXPG227911 COM P.C.B. 1
PCB6 SXPG2243220 HP P.C.B. 1
PCB7 SXPG226611A MKB1 P.C.B. 1
PCB8 SXPG226611B MKB2 P.C.B. 1
PCB9 SXPG218221 PKB P.C.B. 1
Q1 2SB709ARTX TRANSISTOR 1 MAIN
Q1 2SC1815TPE2 TRANSISTOR 1 FJASP
Q2 2SA830STPB TRANSISTOR 1 CPL
Q2 2SB709ARTX TRANSISTOR 1 MAIN
Q2 2SC1815TPE2 TRANSISTOR 1 FJASP
Q3 2SA1015TPE2 TRANSISTOR 1 FJASP
Q3 2SA830STPB TRANSISTOR 1 CPL
Q3 2SD601AQTX TRANSISTOR 1 MAIN
Q4 2SA830STPB TRANSISTOR 1 CPL
Q4 2SC1815TPE2 TRANSISTOR 1 FJASP
Q5 2SA1015TPE2 TRANSISTOR 1 FJASP
Q5 2SA830STPB TRANSISTOR 1 CPL
Q5 2SD601AQTX TRANSISTOR 1 MAIN
Q6 2SA1015TPE2 TRANSISTOR 1 FJASP
Q6 2SA830STPB TRANSISTOR 1 CPL
Q6 2SD601AQTX TRANSISTOR 1 MAIN
Q7 2SB621ARSTA TRANSISTOR 1 MAIN
Q7 2SD592ARSTA TRANSISTOR 1 FJASP
Q8 2SB621ARSTA TRANSISTOR 1 FJASP
Q8,Q9 2SC1815TPE2 TRANSISTOR 2 MAIN
Q9 2SD592ARSTA TRANSISTOR 1 FJASP
Q10 2SB621ARSTA TRANSISTOR 1 FJASP
Q11 2SC1815TPE2 TRANSISTOR 1 FJASP
Q12 2SA1015TPE2 TRANSISTOR 1 FJASP
Q13 2SC1815TPE2 TRANSISTOR 1 FJASP
Q14 2SA1015TPE2 TRANSISTOR 1 FJASP
Q15 2SA1725PY TRANSISTOR 1 FJASP
Q16 2SC4511PY TRANSISTOR 1 FJASP
Q17 2SA1725PY TRANSISTOR 1 FJASP
Q18 2SC4511PY TRANSISTOR 1 FJASP
Q20 2SA933STRS TRANSISTOR 1 FJASP
R1 ERDS2TJ103T 10K 1 FJASP
R1 ERDS2TJ472T 4.7K 1 CPL
R1 ERG1SJ470 47,1W,FLAME-PROOF 1
HP
R2 ERDS2T0T 0,1/4W 1 CPL
31
