Operation & Maintenance Manual
CD-135 / CD-155
OM-02-02
Chapter:
Issue:
Issue date:
Page:
Content:
02-OM-06-02
4
30.07.2014
56
74
Revision no.:
Revision date:
7
20.07.2016
8. Attach the new o-ring to the filter cap. See Fig. 6.46.
Fig. 6.45 Mounting direction of the oil filter
Fig. 6.46 Gearbox oil filter assembling
a Filter element with o-ring
bO-ring
c Filter cap with spring
a
b
c
 Note: Make sure that the spring in the filter cap is fixed.
