2.3 Engine Views
Front view CD-135 / CD-155
 Note: The indications "right", "left", "front" and "rear" are always
relative to the flight direction. The following symbol is used: 
Example of flight direction right:
Fig. 2.1 Front view of CD-135 / CD-155 (dimensions in mm)



