Operation & Maintenance Manual
CD-135 / CD-155
OM-02-02
Revision no.:
Revision date:
Chapter:
Issue:
Issue date:
Page:
Content:
02-OM-02-02
4
30.07.2014
1
4
-
-
2 Description and Dimensions of the
Engine
2.1 Engine Designation
CD-135 (TAE 125-02-99)
CD-155 (TAE 125-02-114)
2.2 Description and Standard Production
Version
The Continental Diesel CD-135 / CD-155 is a liquid-cooled
4-cylinder in-line four-stroke diesel engine with DOHC (double
overhead camshaft). The valves are activated by cam followers.
The operation of the direct diesel-injection engine is based on the
common-rail technique and is turbo charged. The engine is
controlled by a FADEC system. The propeller is driven via an
integrated gearbox (i=1.69) with a clutch or dual mass flywheel.
The engine is equipped with an electric starter and an alternator.
Scope of Supply
The following components and assemblies are included in the
scope of supply of the CD-135 / CD-155:
• Turbocharger
• Integrated propeller controlling and adjusting unit
• Alternator
• Starter
• FADEC system
• Wiring harness
• all of the actuators and sensor required for engine operation
• Vacuum pump
• Water pump
• Engine shock mounts
• Injection system
• Fuel feed pump and high-pressure fuel pump
• Oil pump
• Gearbox
