Fig. 6.5 Air temperarture sensor and MAP connections
of the intake manifold
a FADEC connection for MAP sensor
b Air temperature sensor
Fig. 6.6 Camshaft sensor 1
a Camshaft sensor FADEC A (1 of 2)
b
a
a
