Technify Motors CD-155 User Manual

Operation & Maintenance Manual
CD-135 / CD-155
OM-02-02
Chapter:
Issue:
Issue date:
Page:
Content:
02-OM-06-02
4
30.07.2014
28
74
Revision no.:
Revision date:
7
20.07.2016
Gearbox without oil cooler
1. Loosen the filter cap of the gearbox oil filter an remove it.
Catch draining oil with an appropriate container.
See Fig. 6.16.
2. Remove the old gearbox oil filter with a M6 screw.
See Fig. 6.17.
Item Part Number Description 1 Description 2 Quantity
1 03-7212-K004001 Filter element 1
2 NM-0000-0121001 Sealing Ring DIN 7603-A30x36-Al 1
Fig. 6.16 Position of the oil filter cap
 Note: The used gearbox oil filter must be labeled, stored in a clean
container and made available to Technify Motors GmbH on
request for the complete engine life time. The label must show
the aircraft serial number, registration number, engine serial
number, operation time and date.
