Technika LCD17DVDID-108 - INSTALLATION; Removing the Base Stand; Wall Mounting Instructions

6
INSTALLATION
MOUNTING ON THE WALL
ThisunitisVESA-compliant,andisdesignedtobewall-mountedwithaVESA-compliant100mmx
100mmmountingkitdesignedforat-panelTVs(soldseparately).Mountthisunitaccordingtothe
directions included with the mounting kit.
Note: Remove the base stand before mounting the unit on the wall.
REMOVING THE BASE STAND
WARNING: The LCD Display is very fragile, and must be protected at all times when removing
thebasestand.Besurethatnohardorsharpobject,oranythingthatcouldscratchordamagethe
LCD display, comes into contact with it. Do NOT place pressure on the front of the unit at any time
because the screen could crack.
1. Disconnect any cables or cords connected to the unit.
2. Lay the unit down on a flat surface, so the back side is facing up, making sure to place a soft
cushioned material (such as a pillow or thick piece of foam) beneath the screen.
3. Remove the four screws and then remove the BASE STAND from the TV.
Four
mounting
holes
100mm
100mm
Size: M4 screws
