PD Meter Pressure
Rating
Stud Size
(Inch)
Tightening Torque -
Dry (FT*LB)
Stud Size
(Inch)
Tightening Torque -
Dry (FT*LB)
Pre 1993
M16
S1 1-1/4 960-1,070
S3 & S5 1-1/2 1,545-1,710 1-1/2 1,545-1,710
S6 1-3/4 2,760-3,050 1-3/4 2,760-3,050
Table 4
PD Meter Pressure Rating Stud Size (Inch) Tightening Torque - Dry (FT*LB)
K12
S1 1 610-675
S3 & S5 1 610-675
S6 1-1/4 690-1,070
S7 1-1/2 1,545-1,710
Table 5
PD Meter Pressure
Rating
Stud Size
(Inch)
Tightening
Torque -
Dry (FT*LB)
Stud Size
(Inch)
Tightening Torque -
Dry (FT*LB)
Stud Size
(Inch)
Tightening
Torque -
Dry (FT*LB)
Pre 1998 1998-2003 2003-Present
JB10
S1 3/4 248-275
S3 & S5 1 610-675 1-1/8 760-840 1-1/8 760-840
S6 1 610-675
S7 1-3/8 1,295-1,430
Table 6
Figure 65
