Techno CNC Systems NK105G2 - Default Chapter; Table of Contents

2
Call: 1-631-648-7481 or Visit: support.technocnc.com
HD Series Manual
NK105G2
TABLE OF CONTENTS
Forklift Guide ............................................................... Page 3
Safety Instructions ............................................................... Page 4
Colleting Guidelines ............................................................... Page 5
l HD Mini Setup ................................................... Page 6
HD Mini Enabling the Machine ................................................... Page 7
HD Series Quick Setup ................................................... Page 8
I.I HD Series Installation ................................................... Page 9 - 11
II Vacuum Pump Installation ................................................... Page 12
HD Series Enabling the Machine ...................................... Page 13
II.I HD Series / HD Mini Start Up ...................................... Page 14
Functions of the Keys .................................................. Page 15
Shift Commands / Combination Keystrokes .............. Page 16
III Operating Tutorials
3.0- Switching Movement to Step or Jog
3.1- Jogging the Machine and Changing from High/Low Jog Speed
3.2- Stepping the machine ..................................... Page 17
3.3- Modifying the Jog Speed and Step Size
3.4- Feedrate Override ..................................... Page 18
3.5- Adjusting the XYZ Position/WCS/User Origin ..................... Page 19
 3.6-LoadingaG-codele .................................................Page20
3.7- Running a G-code File ..................................... Page 21
IV Advanced Tutorials
4.1- Alternating between Override and Programmed Feedrates . Page 22
 4.2-SettingOverridespeedforaG-codele...........................Page23
4.3- Setting the Table Size .................................... Page 24
Changing to Different Offset (a new XY Zero location) .............. Page 25
 NotesontheG-codele AccelerationSet........................Page26
V Appendix
HD Series and HD Mini Settings .............................Page 27 - 33
HD Mini Tabletop Settings .................Page 34 - 41
Using the 4th Axis on an HD Machine ................ Page 42
Using the 4th Axis on an HD Mini Machine ................ Page 43
HD Mini 4th Axis Settings ................ Page 44 - 50
VI HD Mini Machine Lubrication ............................... Page 51 - 52
HD Machine Lubrication ...................................... Page 53
Becker Vacuum Pump Manual ............................... Page 54 - 58
Becker Vacuum Pump Filter Inspection ............................... Page 59 - 61
Becker Vacuum Pump Greasing Process ............................... Page 62 - 66
VII Warranty .............................................................. Page 67
