HD Series Manual
NK105G2
HD Mini Tabletop Settings
Website:support.technocnc.com | Call: 631-648-7481
Page | 2
1. Park Mode
Not Move
To Park Site
To WCS Origin
2. Park Site
1. Input Site
Input Park Site
X: _____
Y: _____
Z: _____
2. Select Site
Select Current Position As
Park Pos by [OK] Key
Return ny [ESC] Key
6. Select WCS
G54 WCS
G55 WCS
G56 WCS
Select by [OK]
7. Array Process
Rows = 2
Columns = 2
Rowspace = 1.969
Colspace = 1.969
Delay = 50
8. Origin List
9. Nearby Process
4. Oper Param
1. G00 Speed
250.000 in/min
2. GXX Speed
100.000 in/min
3. Back REF First
YES
4. Lifts on Pause*
-0.394 inch
5. Offset 
1. Public Offest
1. X
2. Y
3. Z
2. Work Offset
1. G54 Offset 
1. X = 0.000
