HD Series Manual
NK105G2
V. Appendix
High/Low Speeds and Step Distances (from main screen, press ‘OK’)
MSpd: 800 / 100
Step XY: 0.005
Step Z: 0.005
File: (active file name) Note: These numbers can vary.
All following settings can be found by pressing the ‘Menu’ key and are worded/abbreviated as
you would see them on screen.
Note: All settings with ‘*’ on screen requires reboot to take effect.
1. LOCAL FILES
2. USB FILES
3. OPERATIONS
1. Back to REF Point
1. All Home
2. Z Home
3. X Home
4. Y Home
2. Rect Machining
1. Params Setting
Engr Depth
Each Depth
Tool Dia
Nose Gap
Height
Width
X Init
Y Init
Mode Horiz Mill
EXECUTE
2. Load the Last
3. Select Line No
Total: ____
StartLine: ____
EndLine:_____
EXECUTE NOW
4. Machining Info
Time
X: _____
Y: _____
Z: _____
5. Park MCS Site
