HD Series Manual
NK105G2
HD Mini 4th Axis Settings
Website:support.technocnc.com | Call: 631-648-7481
Page | 5
Y: Negative
Z: Negative
3. Pulse Equiv *
X: 0.005000 (Mini)
Y: 0.005000 (Mini)
Z: 0.002500 (Mini)
4. Machine Stroke 
1. Strk Upper Lmt 
X: 23.622
Y: 35.433
Z: 0.000
2. Strk Lower Lmt 
X: 0.000
Y: 0.000
Z: -5.900
5. Ref Point Set 
1. RefP Speed 
X: 70.866 in/min
Y: 70.866 in/min
Z: 59.055 in/min
2. RefPDir
X: Negative
Y: Negative
Z: Positive
3. Retract Dist
1. X Retract Dist
0.079 in
2. Y Retract Dist
0.079 in
3. Z Retract Dist
0.079 in
6. Spindle Set 
1. Spindle Gears*
7
2. On/Off Delay
5000 ms
3. Initial Gear*
6
4. Max Spdl Speed*
24000 in/min
7. Y Rotary Axis 
1. Y as Rotary Axis*
NO
2. Rotary Y Pulse
