BIKE XT: Service & Maintenance manual - rev. 2.0
Page 6.2
6.1. THE DISPLAY DOES NOT ILLUMINATE
Are the fuses OK?
Is the mains lead OK?
Does the wall output supply the
correct voltage?
Is the mains voltage present at
the output of the machine’s input
socket?
Replace blown fuses
Replace mains lead
Connect machine to a
suitable
electrical output
Replace input
socket/on-off switch
unit on the machine
Replace cable BX-3
connecting the input
socket/switch unit to
the power supply
THE DISPLAY
DOES NOT
ILLUMINATE
Is the mains voltage present at
the power supply input?
NO
YES
NO
YES
NO
YES
NO
YES
YES
1
2
NO
A
Continued on following page.
