4. Use the seal installer to press the shaft seal into the cylinder head as far
as possible.
5. Remove the seal guide from the shaft.
6. Place the seal guide on the end of the shaft.
7. Place the shaft seal cover on the seal guide and slide the shaft seal cover
into the cylinder head.
8. Remove the seal guide from the shaft.
