Inspection
The shaft seal must never be reused. Always use a new shaft seal when
reassembling a compressor. Be extremely careful to make sure the lip of the
shaft seal that is being installed is not scratched or damaged in any way. Make
sure the shaft seal is free of lint and dirt that could damage the shaft seal
surface.
Installation of Shaft Seal
1. Clean the front section of the cylinder head that holds the front seal.
2. Apply clean PAG compressor oil to the shaft seal and to the front cylinder
head. If the slip surfaces are dirty, clean them with thinners, dry the clean
surfaces and apply clean PAG compressor oil.
3. Place the seal on the seal guide and slide the seal into the cylinder head.
