Instruction manual ITEM TE550 S.p.A.
22/92
QUALITY - T* IDENT
IDENT. MIN 0.000 – 6.000 mm
IDENT. MAX 0.000 – 6.000 mm
QUALITY - T* TH+ID
THICK. MIN 00.00 – 60.00 mm
THICK. MAX 00.00 – 60.00 mm
IDENT. MIN 0.000 – 6.000 mm
IDENT. MAX 0.000 – 6.000 mm
QUALITY - T* ZERO
INPUT VE/PRE (FEATURES MENU) PRE
PRES. MIN 0.00 - 10.0 bar
PRES. MAX 0.00 - 10.0 bar
Existing particular conditions:
 If the OFF TIME is set to 0, the control unit will work in single cycle.
 By setting the PRE-WELD parameter to zero, the pre-welding process will not be carried
out.
 By setting the POST-WELD parameter to zero, the post-welding process will not be carried
out.
 By setting the same value for both CURR. MIN and CURR MAX, the limits of current are
disabled.
 By setting the same value for both ANGLE MIN and ANGLE MAX, the limits of the
conduction angles are disabled.
 By setting the same value for both THICK. MIN and THICK. MAX, the limits are disabled.
 By setting the same value for both IDENT. MIN and IDENT. MAX, the limits are disabled.
 By setting the same value for both PRES. MIN and PRES. MAX, a programming error is
generated.
