Instruction manual ITEM TE550 S.p.A.
2.12 - PROG. SEQUENCE
-TE550 VER. 3.31--
PROGRAM COPY
CHECK INPUT
>PROG. SEQUENCE
The parameters necessary for activating the program sequence operating mode are entered
in this menu. When using this operating mode, the welding control unit orders the welder to
carry a welding spots sequence out by automatically deciding both the working program at
each spot and the spots welding order without needing a program external selection.
PROG. SEQUENCE
>STEP 1 PRG. 003
STEP 1 WELDS 07
STEP 2 PRG. 012
PROG. SEQUENCE MENU PARAMETERS TABLE
PARAMETER PARAMETER DESCRIPTION VALUE RANGE
STEP 1 PRG. Program to be carried out in the step 1 000 – 250
STEP 1 WELDS Number of spots to be carried out with step 1 01 – 25
STEP 2 PRG. Program to be carried out in the step 2 001 – 250
STEP 2 WELDS Number of spots to be carried out with step 2 00 – 25
STEP 3 PRG. Program to be carried out in the step 3 001 – 250
STEP 3 WELDS Number of spots to be carried out with step 3 00 – 25
STEP 4 PRG. Program to be carried out in the step 4 001 – 250
STEP 4 WELDS Number of spots to be carried out with step 4 00 – 25
STEP 5 PRG. Program to be carried out in the step 5 001 – 250
STEP 5 WELDS Number of spots to be carried out with step 5 00 – 25
STEP 1 PRG.
This parameter indicates the program number that the welder has to carry out and is always
coupled with the STEP 1 WELDS parameter.
When this parameter is set to zero, the programs sequence is disabled.
STEP 1 WELDS
This parameter’s value indicates the welding spots number to be carried out with the program
coupled with the same step.
STEP 2 PRG.
This parameter indicates the program number that the welder has to carry out and is coupled
with the STEP 2 WELDS parameter.
STEP 2 WELDS
This parameter’s value indicates the welding spots number to be carried out with the program
coupled with the same step.
STEP 3 PRG.
This parameter indicates the program number that the welder has to carry out and is coupled
with the STEP 3 WELDS parameter.
50/92
