2.9 - FEATURES MENU
-TE550 VER. 3.31--
SETUP MENU
STEPPER MENU
>FEATURES MENU
The features menu contains the parameters that describe the complexity and typology of the
welder on which the control unit works. Due to their importance, access to this menu is
protected by a code.
ENTER ACCESS CODE
FOR FEATURES MENU
- - - - -
If the user is not authorized to enter this menu and does not know the access code, the
following message is displayed:
WRONG CODE
TRY AGAIN!
The parameters can be edited only after having typed in the access code.
Keep in mind that only skilled personnel are permitted to edit the following
parameters to prevent damage to people or equipment.
PARAMETER PARAMETER DESCRIPTION VALUE RANGE
FIRST INSERT. 1st Insertion delay 01 –99
SERIAL COM. Serial communication 232 – 485 – USB – OFF
NETWORK ADDRESS Network address 01 – 31
COIL RATIO Rogowski ratio X 0.5 – X1 –X5 – X10
LOCK/END OUT Output function END – LOCK
FUNCTION RIC6-7 Recall function 6 and 7 RIC – BIC
LOW FORCE SQ. Low force squeeze ON - OFF
FORGE Forging ON – OFF
PROP. VALVE Proportional valve ON - OFF
PRESSURE RATIO Proportional ratio 0.1 – 2.0
AUTORETAIN Start Autoretain ON – OFF
NC CONTACTS Also NC functions of the cycle starts OFF
SEAM WELD MODE Spots / seams ON – OFF
BUTT WELD MODE Butt weld function ON – OFF
SER. SPOT MODE High speed function ON – OFF
CASCADE MODE Electric cascade function ON – OFF
ADJUST POWER% Power map correction 00 - 10
WELD / NO WELD WELD / NO WELD management INT – EXT – BOTH
THICK SENSOR Position sensor function ON – OFF
EV LOCK ON ERR. Head lock function in case of error ON – OFF – KEY
INPUT VE/PRE Input selector VE/PRE VE – PRE
VOLTAGE RANGE Electrodes voltage capacity 5V – 10V – 20V
BACKUP USB Usb backup function <+>
RESTORE USB Usb restore function <+>
SET DATE-TIME Usb set calendar-clock <+>
