S.p.A. ITEM TE550 Instruction manual
CHAPTER 3 - SEAM WELD WORK MODE
FEATURES MENU
AUTORETAIN ON
NC CONTACTS OFF
>SEAM WELD MODE ON
With parameter SEAM WELD MODE set to ON, the work screen is as follows:
PROG. 001 SPOT 12340
WELD CYCLE 01.0 ~
CURRENT RMS 43.26 kA
CONDUCTION DEG 142°
This function allows the user to adapt the control unit to the requirements of a seam welder.
Consequently, welding current is supplied either continuously or via parameter COLD 2 in
pulse mode.
The welding current is measured during the WELD time only regardless of the program set-
up, that is to say either pulsed cycle or continuous cycle.
With the cycle-start command ON, the control unit keeps repeating the time set in the WELD
parameter. We suggest using short weld times to prevent the control unit from finishing a long
weld time, when the cycle start command is cleared.
In the seam operating mode, output EV3 is used as the roller-start command instead of being
used for the forging. On selecting the seam weld function, the control unit may work either in
WORKING MODE in FIX or in IK.
SEAM WELD MODE PARAMETERS TABLE
Below you may see the 2 possible programming screens according to the parameter selected
in the WORKING MODE. The screens contain all the programmable parameters.
PROGRAM DATA
>PROGRAM N. 001
WORKING MODE FIX
CONTROL MODE NO
PARAMETER VALUE RANGE
PROGRAM N. 001 - 250
WORKING MODE FIX
CONTROL MODE * NO
SQUEEZE 1 00.5 – 99.5 cycles
SQUEEZE 00.5 – 99.5 cycles
PRESSURE 00.5 – 10.0 bar
MOTOR DELAY 00 - 99 cycles
SLOPE UP 00 - 25 cycles
WELD 00.5 - 99.5 cycles
POWER 5 - 99 %
COLD 2 00 – 50 cycles
POWER 3 05 – 99 %
HOLD TIME 00.5 – 99.5 cycles
OFF TIME 00.0 – 99.5 cycles
61/92
