Instruction manual ITEM TE550 S.p.A.
CONTROL MODE * CURR
CURR. MIN 0.5 - 90.0 kA
CURR. MAX 0.5 - 90.0 kA
CONTROL MODE * DEG
ANGLE MIN 005°-180°
ANGLE MAX 005°-180°
CONTROL MODE * ALL
CURR. MIN 0.5 - 90.0 kA
CURR. MAX 0.5 - 90.0 kA
ANGLE MIN 005°-180°
ANGLE MAX 005°-180°
-- PROGRAM DATA --
>PROGRAM N. 001
WORKING MODE IK
CONTROL MODE NO
PARAMETER VALUE RANGE
PROGRAM N. 001 - 250
WORKING MODE IK
CONTROL MODE * NO
SQUEEZE 1 00.5 - 99.5 cycles
SQUEEZE 00.5 - 99.5 cycles
PRESSURE 00.5 - 10.0 bar
MOTOR DELAY 00 - 99 cycles
SLOPE UP 00 - 25 cycles
WELD 00.5 - 99.5 cycles
CURRENT 00.5 - 90.0 kA
COLD 2 00 – 50 cycles
CURRENT 3 00.5 – 90.0 kA
HOLD TIME 00.5 - 99.5 cycles
OFF TIME 00.0 - 99.5 cycles
CONTROL MODE * CURR
CURR. MIN 0.5 - 90.0 kA
CURR. MAX 0.5 - 90.0 kA
CONTROL MODE * DEG
ANGLE MIN 005°-180°
ANGLE MAX 005°-180°
CONTROL MODE * ALL
CURR. MIN 0.5 - 90.0 kA
CURR. MAX 0.5 - 90.0 kA
ANGLE MIN 005°-180°
ANGLE MAX 005°-180°
