TABLE CONSTANT ENERGY OPERATING MODE PARAMETERS
PROGRAM DATA
>PROGRAM N. 001
WORKING MODE ENE
CONTROL MODE CUR
PARAMETER VALUE
RANGE
PROGRAM N. 001 - 250
WORKING MODE ENE
CONTROL MODE * NO
QUALITY – T * OFF
SQUEEZE 1 00.5 - 99.5 cycles
SQUEEZE 00.5 - 99.5 cycles
PRESSURE 00.5 - 10.0 bar
FORGE DELAY 00 - 99 cycles
FORG.PRESS. 00.5 - 10.0 bar
SLOPE UP 00 – 25 cycles
WELD MIN 00.5 - 99.5 cycles
WELD MAX 00.5 - 99.5 cycles
POWER 05 - 99 %
ENERGY 00060-60000 joule
COLD 3 00 – 50 cycles
POST-WELD. 00.0 – 99.5 cycles
POST-POWER 05 – 99 %
HOLD TIME 00.5 - 99.5 cycles
OFF TIME 00.0 - 99.5 cycles
CONTROL MODE * CURR
CURR. MIN 1.0 - 90.0 kA
CURR. MAX 1.0 - 90.0 kA
CONTROL MODE * DEG
ANGLE MIN 005°-180°
ANGLE MAX 005°-180°
CONTROL MODE * ALL
CURR. MIN 0.5 - 90.0 kA
CURR. MAX 0.5 - 90.0 kA
ANGLE MIN 005°-180°
ANGLE MAX 005°-180°
QUALITY - T* THICK
THICK. MIN 00.00 – 60.00 mm
THICK. MAX 00.00 – 60.00 mm
QUALITY - T* IDENT
IDENT. MIN 0.000 – 6.000 mm
IDENT. MAX 0.000 – 6.000 mm
