S.p.A. ITEM TE550 Instruction manual
EXAMPLE:
The parameters outlined in the table below were set (with a set work program such as, for
example, “WORKING MODE” IK) with an initial current value set to 10KA.
PARAMETER VALUE
DRESSING NUMBER
3
SPOT DRESSING
200
DRESSING STEPS
30%
DRESSING ALARM
20
ELECTRODES ALARM
20
DRESSING OFFSET
5 %
The chart below shows the pattern of how the current increased during the electrodes
dressing run mode.
Notice that the initial current of the first dressing starts at 10KA whilst a percentage is added
to the starting current value of the subsequent dressings (parameter DRESSING OFFSET).
55/92
