Tecnam P92-JS - Page 69

FLIGHT MANUAL
Date: Issue 3: 25
th
May 2010
P92-JS
S E C T I O N 6
WEIGHT & BALANCE
6-9
EQUIPMENT LIST
A/C S/N
DATE:
REF.
DESCRIPTION & P/N
INST
WEIGHT kg
DATUM m
ENGINE & ACCESSORIES
A1
Engine Rotax 912S2 - p/n 309.120.133
*
59.0
0.32
A2
Prop. HOFFMANN p/n HO17GHM-174-177C
or HO17GHM A 174 177C
*
4.50
-0.08
A3
Exhaust and manifolds –
p/n SSB-978-480-CC
*
4.50
0.55
A4
Heat exchanger - p/n 92-11-830
*
2.00
0.55
A5
Oil Reservoir (full) - p/n 956.137
*
4.00
0.61
A6
Oil radiator - p/n 886 025
*
0.40
0.07
A7
Liquid coolant radiator. - p/n 995.697
*
0.90
0.33
A8
Air filter K&N- p/n 33-2544
*
0.40
0.60
A9
Vacuum instr. system – RA215CC Rapco
3.00
0.25
A10
Vacuum valve RA2H3-12
0.100
0.71
A11
0.110
0.71
A12
Fuel pump p/n 21-11-342-000
*
0.200
0.71
A13
Fuel tank. 35 LT. P/N 21-1-300-001/2
//
//
A14
Fuel tank. 45 LT. P/N 21-1-340-001/2
//
//
LANDING GEAR AND ACCESSORIES
B1
Main gear spring-leafs - p/n 92-8-300-1
*
5.700
1.930
B2
Main gear wheel rims. - Cleveland 40-78B
*
2.050
1.930
B3
Main gear tires.-Air Trac 5.00-5 AA1D4
*
2.580
1.930
B4
Disk brakes - Cleveland 30-9
*
0.800
1.930
B5
Nose gear wheel rim - p/n 92-8-880-1
*
1.300
0.310
B6
*
1.200
0.460
B7
Nose gear fairing p/n 92-8-410-1/2
x
1.500
0.460
B8
Main gear fairing p/n 92-8-420-1/2
x
1.500
1.930
B9
Nose gear shock p/n 92-8-200-000
*
1.450
0.465
ELECTRICAL SYSTEM
C1
Battery FIAMM 6H4P 12V 18Ah
*
6.00
4.24
C2
Regulator, rectifier - p/n 945.345
*
0.20
0.82
C3
Battery relay - p/n 111-226-5
*
0.30
4.19
C4
Flaps actuator control - SIR Mod. AO-01/M
*
2.20
2.57
C5
Trim actuator control Ray Allen C. T2-10A
*
0.40
5.75
