Tecnam P92-JS - DESCRIPTIVE DATA

FLIGHT MANUAL
Date: Issue 3: 25
th
May2010
I-4
P92-JS
S E C T I O N 1
GENERAL
DESCRIPTIVE DATA
WING
For 550 kg
MTOW
For 600 kg
MTOW
Wing span:
8.7 m
8.7 m
Wing chord
1.4 m
1.4 m
Wing surface
12 m
2
12 m
2
Wing loading
45.8 kg/m
2
50.0 kg/m
2
Aspect ratio
6.31
6.31
Taper ratio
1.0
1.0
Dihedral
1.5°
1.5°
FUSELAGE
Overall length
6.400 m
6.400 m
Overall width
1.100 m
1.100 m
Overall height
2.500 m
2.500 m
EMPENNAGE
Stabilator span
2.900 m
2.900 m
Vertical tail span
1.230 m
1.230 m
LANDING GEAR
Wheel track:
1.800 m
1.800 m
Wheel base:
1.600 m
1.600 m
Main gear tires: Air Trac;
Cleveland wheel hub and brakes kit:
5.00-5
199-102
5.00-5
199-102
Nose gear tire: Sava
4.00-6
4.00-6
CONTROL SURFACES TRAVEL LIMITS
Ailerons
Up 20° down 15 °  2°
Stabilator
Up 18° down 3°  1°
Trim-Tab
2° ; 12°  1°
Rudder
RH 25° LH 25°  1°
Flaps
0° -38°  1°
