Tecnam P92-JS - BRAKES; MARKING & PLACARDS

FLIGHT MANUAL
Date: Issue 3: 25
th
May 2010
7-11
P92-JS
S E C T I O N 7
SYSTEMS
BRAKES
The aircraft's braking system is a single system acting on both wheels of main
landing gear through disk brakes, the same circuit acts as parking brake via an
intercept valve.
To activate brakes it is sufficient to verify that brake shut-off valve positioned
on tunnel between pilots is OFF, then activate brake lever as necessary.
To activate parking brake pull brake lever and set brake shut-off valve to ON.
MARKING & PLACARDS
To compensate for deviation errors of the magnetic compass, the following
correction card is located immediately below compass:
This placard has to be compiled by certified operator with valid and proper
instrumentation.
The following placard is located on the cabin's floor tunnel, near the hydraulic
brake circuit shutoff valve:
Refer to section 9 for possible variations.
For
N
30
60
E
120
150
Steer
For
S
210
240
W
300
330
Steer
DATE
RADIO ON
AIRPATH
