Tecnam P92-JS - ELECTRICAL SYSTEM

FLIGHT MANUAL
Date: Issue 3: 25
th
May 2010
7-8
P92-JS
S E C T I O N 7
SYSTEMS
ELECTRICAL SYSTEM
The aircraft's electrical system consists of a 12 Volt DC circuit controlled by
the Generator Switch located on the instrument panel. Electricity is provided
by an alternator and by a buffer battery placed in the fuselage tail section.
Generator light is located on the right side of the instrument panel.
If the ignition key is in the position L, R or BOTH an accidental
movement of the propeller may start the engine with possible danger
for bystanders.
FIG. 7-4. ELECTRICAL SYSTEM SCHEMATIC
WARNING
