The following placard is located in proximity of fuel filler caps (28x63mm):
The following placards are located on oil reservoir:
The following label is located below each door for emergency opening:
Main landing gear tire inflation pressure is indicated in the
following label affixed on each spring-leaf strut:
The following label indicates inflation pressure for nose
gear tire and is affixed on nose gear assy:
The 0° reference mark for stabilator balance is located on
left hand side of tail cone in proximity of stabilator
