Use and Maintenance Manual
MaxX
N
S
N
S
N
S
3.3
Magnetic force
Each pole (North/south) is an independent magnetic
island, consisting of a conductive steel core of magnetic
flux, able to generate a high value of magnetic force
concentrated and constant over time. The total magnetic
attraction force available is directly proportional to the
magnetic operating surface, the type of material of which
the load to be lifted and the conditions of its surface are
composed; i.e. from:
Load to be lifted
(mild steel, alloy steel, cast iron ...)

Load surface conditions (roughness, flatness...)
Contact surface between load and MaxX
Fig.3.3A Fig.3.3B
The following graphs/curves are exhaustive of further
information concerning the magnetic force and the load in
function of the air gap.
C
= Load
F
= Force
T
=Airgap
Fig.3.3C
Fig.3.3D
Fig.3.3E
The ones presented are indicative values, obtained with
loads in common steel S275JR, at a temperature of 20 °c.
4 MODELS AVAILABLE
4.1
MaxX
The MaxX lifting system is a product of Tecnomagnete and
is available in the models:

MaxX 125
–
MaxX 250
–
MaxX 300E
–
MaxX 500
–
MaxX 600E
MaxX 1000
–
MaxX 1500
–
MaxX 2000
:
Fig.4.1A

MaxX TG 150 – MaxX TG 300
:
Fig.4.1B
MaxX
LOAD
Anchorage force
0 0,25 0,5 0,75 1,00 1,25 1,50
T [
mm
]
C
[
Kg
]
2000
1500
1000
600E
500
300E
250
0
F
[
daN
]
6000
4500
3000
1500
750
0 0,25 0,5 0,75 1,00
T [
mm
]
C
[
Kg
]
F
[
daN
]
T
=Air gap
0 0,25 0,5 0,75 1,00
T [
mm
]
F
[
daN
]
900
675
450
225
C
[Kg]
300
225
150
75
0
LOAD
EXAMPLE
EXAMPL
E
