8
codice 09MAXX001
versione EN
revisione 01
Use and Maintenance Manual
MaxX
When hoisting or handling MaxX, clear the operations
area of obstructions and keep it clear, also consider
providing a sufficient safety zone to prevent harm to
persons, animals or objects that might be in maneuvering
range. MaxX are designed to be hoisted and handled
with suitable hoisting devices, the type and scope of
which must be selected in accableance with the weight.
(see table Fig.2.2C). It must be handled with extreme
care, avoiding impacts that could damage delicate parts,
compromising normal operation When moved with
forklift trucks, comply with the permitted speed and
inclination. Never leave load suspended on hoists. (also
refer to paragraph 1.8).
The permanent-electro magnetic system must be
disconnected from power sources and its moving parts
appropriately locked during transport, handling and
storage.
The instructions on the package must be read and
digested before opening.
Keep the original packaging for later handling.
2.3
Transport
Some parts may have to be dismantled for transport, to be
reassembled and reconnected during installation by
TECNOMAGNETE S.p.A. technicians, or by the User on
TECNOMAGNETE S.p.A.’s recommendations.
The system must be
transported in observance of the following environmental limits:
a temperature range of -5 °C to +55 °C, rising to a maximum of
+70 °C for a period no longer than 24 hours.
Should it be
necessary to transport the MaxX by sea or by air, suitable
packaging and protection systems must be provided to avoid
any damage caused by impact. To protect against weathering,
use anti-rust lubricants and bags of hygroscopic salts inside the
packages. All moving parts must be properly anchored and
removed from their housing, where possible.
2.4
Inactivity
In the event of long-term storage or inactivity, the MaxX must be
thoroughly cleaned of any residues and its uncovered metallic
parts must be protected with oil or grease in order to avoid
oxidation. It is recommended to cover the MaxX with a tarpaulin
and keep them in a dry, sheltered place The room temperature
should be between -5 ° C (23 ° F) and + 55 ° C (131 ° F). The
relative non-ondensing humidity should be between 30% and
90%, The atmosphere should be clean, free of acids, corrosive
gases, salts, etc. If restoring to operation, follow the instructions
contained in this manual.
3 DESCRITPION OF THE
SYSTEM
3.1
Advantages
MaxX consists of a very small number of details. Rotor and
stator, in steel with high magnetic permeability, are obtained by
machining from solid, using CNC machines; this grants uniformity
and robleness of the product and the quality control necessary
for a magnetic hoist built in large series.
The material used (steel, aluminum, plastic) is easily disposable
and recyclable when the tool is dismantled.
The magnetic material used, with a high specific energy, made it
possible to reduce to the maximum weight and volume.
To allow a high uniformity of performance, given the large series,
the MaxX lifter is magnetized in a single stroke after assembly,
using the largest magnetizer built in Europe.
MaxX is able to handle the load, which is always anchored and
lifted from above, without any deformation or damage with an
optimal use of the available work areas.
Some of the most recognized areas with the use of MaxX are the
following:
- servicing of machine tools
- wholesalers of ferrous material
- cutting plants
- carpentry
- shipyards
- foundries
- steel industries
- mold handling
