TECNOMAGNETE MaxX 125 - Max Xdimensions and Weights

13
codice 09MAXX001
versione EN
revisione 01
Use and Maintenance Manual
MaxX
50
°
1
2
5
°
5
0
°
1
2
5
°
5
0
°
1
2
5
°
B
A
FI
C
E
D
H
G
M
ON
OFF
OFF
OFF
ON
ON
I
C
D
E
H
L
L
B
A
F
G
M
F
G
M
B
A
D
E
H
C
L
I
5.2
MaxX
dimensions and weights
Fig.5.2A
Fig.5.2B
Model
Weig
ht
[kg]
Dimensions [mm]
A B C D E F G H I L M
MaxX 125
3,7 121 76 79 79 66 30 44 145 132 137
10
MaxX 250
6 189 143 79 79 63 35 43 142 130 137
10
MaxX 500
15 250 199 106 101 88 52 60 189 165 170
14
MaxX 1000
36 342 284 133 131 88 52 60 219 225 240
14
MaxX 1500
66 383 316 166 171 122 64 87 293 330 377
19
MaxX 2000
80 457 390 166 171 122 64 87 293 330 377
19
MaxX 300E
6 189 143 79 79 63 35 43 142 130 137
10
MaxX 600E
15 250 199 106 101 88 52 60 189 165 170
14
MaxX TG150
6 189 170 79 87 63 35 43 150 130 137
10
MaxX TG300
16 250 230 106 101 88 52 60 189 165 170
14
