F_22: Reverse Lockout = 0: REV run command enabled
= 1: REV run command Lockout
NOTE:
When F_04 (motor rotation direction) is set to 1 (reverse), F_22 cannot be set to 1.In order to properly lockout a motor direction,
F_04 must be set at 0 before setting F_22 to 1.
F_23: Auto-restart after Momentary Power Loss = 0: Auto-restart enabled
= 1: Auto-restart disabled
1. When the AC power supply is temporarily below low voltage protection levels due to low line supply or unusually large
demands on the power supply system,the AC drive will stop immediately. If the voltage level recovers within 2 seconds,
the AC drive can restart by using its speed search program.
2. When F_23 = 0:
(1) If the momentary power loss is less than 2 seconds, the AC drive resumes operation automatically via speed search at 0.5
seconds after power up.The number of auto restart times is not limited by F_24.
(2) If the momentary power loss is long, the operation of the AC drive is based on the setting of F_10 and the condition of the
external switch.
(3) If the time of momentary loss is between the above two conditions,whether the AC drive will auto-restart depends
on F_24:
F_24 = 0: Auto-restart disabled.
F_24 = 1 ~ 5: Auto-restart enabled 1~5 times.
46
FLUXMASTER 50 INSTRUCTION MANUAL
