TECO JSDAP-100A3 User Manual

5-38
4. Parameter Setting for Electronic Gear Ratio
Setting gear ratio Numerator and denominator parameters:
Numerator and denominator values of the calculated electronic gear ratio must be entered in the
required parameters.
These two values have to be integer and with a value within the specified range in the table below.
Parameter
Signal
Name Default Unit
Setting
Range
Control
Mode
Pn302 Numerator of Electronic Gear Ratio 1 1 X 1~50000 Pi/Pe
Pn303 Numerator of Electronic Gear Ratio 2 1 X 1~50000 Pi/Pe
Pn304 Numerator of Electronic Gear Ratio 3 1 X 1~50000 Pi/Pe
Pn305 Numerator of Electronic Gear Ratio 4 1 X 1~50000 Pi/Pe
★
Pn306
Denominator of Electronic Gear Ratio 1 X 1~50000 Pi/Pe
★ New setting will become effective after re-cycling the power.
This device provides 4 selections of Numerator for Electronic Gear Ratio.
Input contacts GN1 and GN2 can be used to select the required Numerator for the Electronic Gear
Ratio
According to the following table.
Input
Contact GN2
Input Contact
GN1
Numerator of Electronic Gear Ratio
Control
Mode
0 0
Numerator of Electronic Gear Ratio 1
Pn302
0 1
Numerator of Electronic Gear Ratio 2
Pn303
1 0
Numerator of Electronic Gear Ratio 3
Pn304
1 1
Numerator of Electronic Gear Ratio 4
Pn305
Pi/Pe
Note: Input contacts status “1” (ON) and “0” (OFF)
Please check 5-6-1 to set the required high /Low signal levels (PNP/NPN) selection.
