1-10
dn-08 Display Motor Standards
Cn030 Setting
Drive Model
JSDAP
Motor Model
Watt(KW) Speed(rpm)
Encoder
Specification
H1401 JSMA-PMB30BB 2500
H1402 JSMA-PMB30BH 8192
H1405 JSMA-PMB30B5 15 bit(ABS)
H1407 JSMA-PMB30B7
3.0 2000
17 bit
H1411 JSMA-PMH30BB 2500
H1412 JSMA-PMH30BH 8192
H1415 JSMA-PMH30B5 15 bit(ABS)
H1417 JSMA-PMH30B7
3.0 1500
17 bit
H1421 JSMA-PMH44BB 2500
H1422 JSMA-PMH44BH 8192
H1425 JSMA-PMH44B5 15 bit(ABS)
H1427
50B
JSMA-PMH44B7
4.4 1500
17 bit
H1501 JSMA-PMH44BB 2500
H1502 JSMA-PMH44BH 8192
H1505 JSMA-PMH44B5 15 bit(ABS)
H1507 JSMA-PMH44B7
4.4 1500
17 bit
H1511 JSMA-PMH55BB 2500
H1512 JSMA-PMH55BH 8192
H1515 JSMA-PMH55B5 15 bit(ABS)
H1517
75B
JSMA-PMH55B7
5.5 1500
17 bit
H1611 JSMA-PMH75BB 2500
H1612 JSMA-PMH75BH 8192
H1615 JSMA-PMH75B5 15 bit(ABS)
H1617
100B
JSMA-PMH75B7
7.5 1500
17 bit
