TECO JSDAP-100A3 User Manual

9-12
※Standard Specifications for JSMA (400V Class)
JSMA-P□□□□
Motor Mode Symbol Unit
MB10B MB15B MB20B MB30B
Drive Model 25B 25B 25B 35B
Rated Output P
R
KW 1 1.5 2 3
Rated Torque T
R
N．m
4.782 7.164 9.545 14.327
Max. Torque T
max
N．m
14.327 21.492 28.645 42.693
Rated Speed N
R
rpm 1500
Max. Speed N
max
rpm 2000
Rated Current I
R
A 2.58 4.36 5.78 8.9
Max. Armature Current I
max
A 7.74 13.08 17.34 26.7
Torque Constant K
T
N．m/A
2.06 1.80 1.76 1.78
Rotor Moment of Inertia J
M
Kg．cm
2
6.26 8.88 12.14 17.92
Armature Resistor Ra Ω 5.38 2.39 1.45 1.07
Armature Inductance La mH 23 12 8.96 5.89
Mechanical Time Constant Tm ms 1.32 0.97 0.865 0.93
Electrical Time Constant Te ms 4.28 5.02 6.18 5.5
Weight(Standard) W kgw 6.47 8.08 10.16 13.87
Insulation Grade ─ ─
Class B (130℃) Class F (155℃)
Operating Ambient Temp. T
℃
0 ~ 40
Operating Ambient Humidity RH % <90
Storage Temp. T
℃
-20 ~ 60
Storage Humidity RH % <90
1( kgf‧cm)＝0.0980665(N‧m) ； 1(gf‧cm‧s
2
)＝0.980665(kg‧cm
2
)
