TECO JSDAP-100A3 User Manual

9-15
※ JSMA-PM/PH motor dimension diagram (200V Class)
200V Class
Motor Mode
LZψ LAψ
LC E W
Sψ LBψ
LE LR LL
MA05
9 145 130.4 2.5 6 22 110 6 58 163.8
MH05
9 145 130.4 2.5 6 22 110 6 58 163.8
MA10
9 145 130.4 2.5 6 22 110 6 58 213.8
MB10
9 145 130.4 2.5 6 22 110 6 58 163.8
MC10
9 145 130.4 2.5 6 22 110 6 58 148.8
MH10
9 145 130.4 2.5 6 22 110 6 58 213.8
MA15
9 145 130.4 2.5 6 22 110 6 58 263.8
MB15
9 145 130.4 2.5 6 22 110 6 58 184.8
MC15
9 145 130.4 2.5 6 22 110 6 58 163.8
MB20
9 145 130.4 2.5 6 22 110 6 58 213.8
MC20
9 145 130.4 2.5 6 22 110 6 58 184.8
MB30
9 145 130.4 2.5 6 22 110 6 58 263.8
MC30
9 145 130.4 2.5 6 22 110 6 58 213.8
MH30
13.5 200 180 3 10 35 114.3 3.2 79 254
MH44
13.5 200 180 3 10 35 114.3 3.2 79 283
MH55
13.5 200 180 3 12 42 114.3 3.2 113 297
MH75
13.5 200 180 3 12 42 114.3 3.2 113 382
MH110
13.5 235 220 3 12 42 200 4 116 352
MH150
13.5 235 220 4 16 55 200 4 116 429
HH30
13.5 200 180 3 10 35 114.3 3.2 79 245
HH44
13.5 200 180 3 10 35 114.3 3.2 79 273.5
HH55
13.5 200 180 3 12 42 114.3 3.2 113 282.5
JSMA-PM
JSMA-PH
Series
Without
Brake
HH75
13.5 200 180 3 12 42 114.3 3.2 113 371
Unit: mm
