TECO JSDAP-100A3 User Manual

3-21
400V Class
dn-08 Display Motor Standards
Cn030 Setting
Drive Model
JSDAP
Motor Model
Watt(KW) Speed(rpm)
Encoder
Specification
H1211 JSMA-PMB10BB 2500
H1212 JSMA-PMB10BH 8192
H1215 JSMA-PMB10B5 15 bit(ABS)
H1217 JSMA-PMB10B7
1.0 2000
17 bit
H1231 JSMA-PMB15BB 2500
H1232 JSMA-PMB15BH 8192
H1235 JSMA-PMB15B5 15 bit(ABS)
H1237 JSMA-PMB15B7
1.5 2000
17 bit
H1251 JSMA-PMB20BB 2500
H1252 JSMA-PMB20BH 8192
H1255 JSMA-PMB20B5 15 bit(ABS)
H1257
25B
JSMA-PMB20B7
2.0 2000
17 bit
H1311 JSMA-PMB20BB 2500
H1312 JSMA-PMB20BH 8192
H1315 JSMA-PMB20B5 15 bit(ABS)
H1317 JSMA-PMB20B7
2.0 2000
17 bit
H1331 JSMA-PMB30BB 2500
H1332 JSMA-PMB30BH 8192
H1335 JSMA-PMB30B5 15 bit(ABS)
H1337 JSMA-PMB30B7
3.0 2000
17 bit
H1341 JSMA-PMH30BB 2500
H1342 JSMA-PMH30BH 8192
H1345 JSMA-PMH30B5 15 bit(ABS)
H1347
35B
JSMA-PMH30B7
3.0 1500
17 bit
