10
Functional specification:
Item Specification
Input Signal Type PNP type (SOURCE) input (External 24VDC Input is allowed)
Control Method Sinusoidal wave PWM control
Freq. Range 1~200 Hz*1
Resolution Setting Digital: 0.1 Hz (1 ~ 99.9 Hz); 1 Hz (100 ~ 200 Hz)
Analog: 1Hz/ 60 Hz
Keyboard Setting
Directly setup by ▲▼ buttons.
External Signal Setting 0~10V, 4 ~ 20mA, 0 ~ 20mA
Freq.
Control
Other function Frequency upper and lower limit
Carrier frequency 4~16KHz*2
Accelerate/Decelerate time 0.1~ 999 Sec
V/F Pattern 6 Patterns
Torque control Torque boost level adjustable (manual torque boost)
Multi-Functional input 2 point, to be used as multi-speed 1(Sp.1) / multi-speed 2(Sp.2) *1/
Jog / External emergency stop / External bb / Reset
Multi-Functional output 1a Relay terminal, to be setup as Fault / Running / Frequency.
Braking Torque 1P2~101/2P2~201:About 20%
202/203/401/402/403: 20%~100%, built-in braking transistor
General
Control
Other function Decelerate or free run stop, Auto reset, DC braking frequency /
Voltage / Time can be setup by constants.
Display Three digital LED display frequency / inverter parameter / fault
record / program version.
Operating temperature -10 ~ +40
O
C (without shield sticker: -10
O
C ~ +50
O
C)
Humidity 0~95% RH non-condensing.
Vibration Under 1 G (9.8 m/s
2
)
EMC specification EN61800-3+A11,EN50178
UL UL508C
Overload protection 150% for 1 min.
Over-voltage DC voltage > 410V(100/200 series); DC voltage > 800V(400 series)
Under voltage DC voltage < 200V(100/200 series); DC voltage < 400V(400 series)
Momentary Power-loss 0 ~ 2 sec: The inverter can be restarted using speed search
feature.
Stall Prevention During Acceleration / Deceleration/ Constant speed
Output Short-circuit Electronic circuitry protection
Grounding fault Electronic circuitry protection
Protection
Function
Other function Heat sink overheat protection, Current limit
Installation Mounting screw or DIN rail (Option).
Note: *1: New function for CPU version v1.9 and above.
*2: Carrier frequency range: CPU version v1.6 is 4~8kHz.
CPU version v1.9 and above are 4~16kHz.
