15
(a) good (b) good (c) not good
(D) Wire specification, apply appropriate wire with correct diameter for primary power circuitry and
control circuitry in accordance with electricity regulations.
Wiring Diagram
Wire Terminations to the Inverter must be made with either UL listed field wiring lugs or UL listed crimp
type ring terminals.
Note: Only for 202/203/401/402/403.
P R
L1 (L)
L2
L3 (N)
FWD
REV
SP1
RST
12V
+10V
MVI
(0~10V/0~20/4~20mA)
0V(FM–)
FM+
*( note)Braking
Re si s t er ( Opt io n)
SW1
1
2
3
(U)T1
(V)T2
(W)T3
1
2
CON2
AC Input
M
}
Trip Relay
Test Points
Grounding
{
Multi-Function
Inputs
8
1
1
F
Speed Pot
10kΩ
~
V
