3.Specification:
Basic specification:
Model : E2-
1P2-H1x
1P5-H1x 101
Suitable Motor Power Rating (KW) 0.2 0.4 0.75
Motor (HP)
0.25 0.5 1
Output Current (A) 1.4 2.3 4.2
Capacity (KVA) 0.53 0.88 1.6
Rated
Weight (Kg ) 0.7 0.72 0.8
Input Voltage Max. Single phase 100-120V (+10%, -15%), 50 / 60Hz (+/-5%)
Output Voltage Max. Three phases 200-240V (Proportional to input voltage)
Dimension W*H*D (mm) 72*132*118
EMC Specification
Without Filter
Model: E2-
2P2-x1xx
2P5-x1xx 201-x1xx
202-Hxxx
203-Hxxx
Suitable Motor Power Rating (KW) 0.2 0.4 0.75 1.5 2.2
Motor (HP)
0.25 0.5 1 2 3
Output Current (A) 1.4 2.3 4.2 7.5 10.5
Capacity (KVA) 0.53 0.88 1.6 2.9 4.0
Rated
Weight (Kg) 0.76 0.77 0.8 1.66 1.76
Input Voltage Max.
Single phase 200-240V
(+10%, -15%), 50 / 60Hz (+/-5%)
Single/Three phases 200-
240V(+10%, -15%),
50 / 60Hz (+/-5%)
Output Voltage Max. Three phases 200-240V (Proportional to input voltage)
Dimension W*H*D (mm) 72*132*118 118*143*172
EMC Specification
Class A (Single Phase Filter built in)
Model : E2- 401-H3xx
402-H3xx
403-H3xx
Suitable Motor Power Rating (KW) 0.75 1.5 2.2
Motor (HP)
1 2 3
Output Current (A) 2.3 3.8 5.2
Capacity (KVA) 1.7 2.9 4.0
Rated
Weight (Kg ) 1.6 1.62 1.68
Input Voltage Max. Three phases 380-480V (+10%, -15%), 50 / 60Hz (+/-5%)
Output Voltage Max. Three phases 380-480V (Proportional to input voltage)
Dimension W*H*D (mm) 118*143*172
EMC Specification
Class A (Three Phases Filter built in)
