Note: The input and relay mappings are specific to each NAC. Additional NACs
require additional mappings of inputs and relays.
The mapped input and relay numbers are indexes into the ChallengerPlus
panel’s device numbering scheme, which depends on the NAC’s address (set via
its DIP switches) and which ChallengerPlus system LAN it is attached to.
NACs may use the first 12 addresses on each ChallengerPlus system LAN.
Table 5 below lists the LAN number, the address of the NAC (set via the NAC’s
DIP switches), the DGP number that the NAC is polled as, and the ranges of
ChallengerPlus input and relay numbers.
Table 5: ChallengerPlus inputs and relays per DGP address
ChallengerPlus
LAN
Address
Polled as
ChallengerPlus
inputs
ChallengerPlus
relays
LAN 1
1
DGP 1
17 to 48
17 to 32
LAN 1
2
DGP 2
49 to 80
33 to 48
LAN 1
3
DGP 3
81 to 112
49 to 64
LAN 1
4
DGP 4
113 to 144
65 to 80
LAN 1
5
DGP 5
145 to 176
81 to 96
LAN 1
6
DGP 6
177 to 208
97 to 112
LAN 1
7
DGP 7
209 to 240
113 to 128
LAN 1
8
DGP 8
241 to 272
129 to 144
LAN 1
9
DGP 9
273 to 304
145 to 160
LAN 1
10
DGP 10
305 to 336
161 to 176
LAN 1
11
DGP 11
337 to 368
177 to 192
LAN 1
12
DGP 12
369 to 496
193 to 208
LAN 2
1
DGP 17
497 to 528
257 to 272
LAN 2
2
DGP 18
529 to 560
273 to 288
LAN 2
3
DGP 19
561 to 592
289 to 304
LAN 2
4
DGP 20
593 to 624
305 to 320
LAN 2
5
DGP 21
625 to 656
321 to 336
LAN 2
6
DGP 22
657 to 688
337 to 352
LAN 2
7
DGP 23
689 to 720
353 to 368
LAN 2
8
DGP 24
721 to 754
369 to 384
LAN 2
9
DGP 25
753 to 784
385 to 400
LAN 2
10
DGP 26
785 to 816
401 to 416
LAN 2
11
DGP 27
817 to 848
417 to 432
LAN 2
12
DGP 28
849 to 880
433 to 448
In order for ChallengerPlus to utilise the mapped inputs and relays, you must
also program the ChallengerPlus input and relays. See the “Programming
mapped inputs and relays” section on page 82 for instructions.
