Commands
The Status and Control window allows the operator to execute remote
commands on the NAC and its devices via context menus.
If you right-click on the NAC, the following options appear in the context menu:
Isolate – isolates the NAC.
De-isolate – de-isolates the NAC.
Battery test – starts a timed battery test.
Cancel test – cancels an undergoing battery test.
Update status – updates the icon and description of the NAC to its
current status.
Update all device status – updates the icons and descriptions of the
NAC and all of its attached DGPs and RASs to their current status.
Note: This option only appears for a NAC panel connection (in IP Direct
and IP Extended modes).
Reboot device – reboots the NAC. CTPlus prompts you for your operator
password
Diagnostics – opens a window showing detailed diagnostics for the NAC,
including its power supply voltage and current, battery status, and state of
inputs.
Upgrade firmware – allows the operator to upgrade the firmware on the
NAC. See the “Upgrading firmware” section on page 36.
If you right-click on a door, the following options appear in the context menu:
Open – opens the door.
Timed open – opens the door for a set period of time.
Unlock – unlocks the door.
Lock – locks the door.
Enable – enables the door.
Disable – disables the door.
Reader status – opens a window showing the status of all readers
assigned to the door.
Update status – updates the icon and description of the door to its current
status.
Diagnostics – opens a window showing detailed diagnostics for the door,
including the state of inputs, relays, and configuration options.
