844E Sprayer Control
Feature:
Based on the tip programmed and nozzle spacing (programmed in the System Setup Mode), the 844 console will
calculate the required speed to achieve the application rate that was entered in the last programming step. The
speed will be displayed in the lower left corner of the display window. Keep in mind that this speed is based on a
spraying pressure of 40 psi (2 bar). More calculations can be performed in the next programming step.
When the correct fl ow rate for the spray tips being used has been entered, press the
key to accept the value
and advance to the next step.
TeeJet® VisiFlo®
Tip Color
Flow Rate in US GPM at
40 PSI
Flow Rate in l/min at
2 bar
Flow Rate in Imperial
GPM at 40 PSI
Orange 0.10 0.32 0.08
Green 0.15 0.48 0.12
Yellow 0.20 0.64 0.17
Blue 0.30 0.97 0.25
Red 0.40 1.29 0.33
Brown 0.50 1.61 0.42
Gray 0.60 1.93 0.50
White 0.80 2.58 0.67
Light Blue 1.00 3.22 0.83
Light Green 1.50 4.83 1.25
Black 2.00 6.45 1.67
