Nozzle Selection
Default = Red or 0.4 US GPM (1.29 l/min) {0.33 Imperial GPM}
While in the nozzle selection step, the display will remain the same as in the Target Application Rate step except
the symbol will be fl ashing at the bottom of the display just above a color coded strip.
NOTE: The tabbed color strip along the bottom of the display represents color coding for TeeJet® VisiFlo® spray
tips. If you are using tips made by another manufacturer, you should use the programmable tip capacity as
explained in the System Setup section on page 19.
Select the representative color to match the spray tips being used to apply the desired application rate. Use the
or keys to toggle the symbol through the tabbed color strip at the bottom of the display panel. The
corresponding fl ow rate for each color will be displayed in US Gallons Per Minute (Liters Per Minute) {Imperial
Gallons Per Minute} at 40 psi (2 bar) at the lower right of the display. If the programmable tip is to be used, toggle
the symbol to the
“
P
”
tab. Flow rate will always be displayed in US Gallons Per Minute (Liters Per Minute)
{Imperial Gallons Per Minute} at 40 psi (2 bar) regardless of any changes to other display parameters.
The table at the bottom indicates fl ow rates in US Gallons Per Minute (Liters per Minute) {Imperial Gallons Per
Minute} at 40 psi (2 bar) for the TeeJet® VisiFlo® color coded spray tips represented in the 844 Spray Control.
WARNING: Color coding of spray tips is not uniform from manufacturer to manufacturer. Flow rates for all
nozzles should be checked prior to use. Tips that are worn should be replaced to ensure an accurate
application rate.
