Tekmar 562 - Application 562-1

6 of 24
© 2017 tekmar 562
_
D - 08/17
Rh1
W1
Rh2
W2
Rc
Y1
G
C
R
AWAY
S1
S2
SEN
COM
C
R
W1
Y
W2
G
Legend
C1 = Air Conditioner
F1 = Furnace
T1 = WiFi Thermostat 562
C1
WiFi Thermostat 562
F1
T1
Application 562-1
Mechanical ----------------------------------------------------------
Electrical -----------------------------------------------------------
The WiFi Thermostat 562 operates a one or two-stage furnace for heating and an air
conditioner for cooling.
Furnace
Terminals
J1 J2 J3
RELAY
POWER
JUMPER
ON
OFF
Thermostat
jumpers:
J1 = On
J2 = On
J3 = On
